Cash Acme 1 in. Bronze Valve

Model: 23156-0045

More From Cash Acme

Cash Acme 1 in. Bronze Valve

Cash Acme 1 in. Bronze Valve

Model: 23156-0045

More From Cash Acme

The EB45 pressure regulator features a half cartridge design that offers the performance of a high end, cartridge based valve and the price of a traditional regulator. The valve construction is similar to a traditional regulator in that it retains a separate spring chamber and adjusting screw, but offers the simplicity and maintenance benefits of a cartridge based valve. The EB45 comes factory set at 45 PSI but may be adjusted between 10-70 PSI.

Sold out.

FREE Shipping on all orders over $75*

The EB45 pressure regulator features a half cartridge design that offers the performance of a high end, cartridge based valve and the price of a traditional regulator. The valve construction is similar to a traditional regulator in that it retains a separate spring chamber and adjusting screw, but offers the simplicity and maintenance benefits of a cartridge based valve. The EB45 comes factory set at 45 PSI but may be adjusted between 10-70 PSI.
The EB45 pressure regulator features a half cartridge design that offers the performance of a high end, cartridge based va...
See more

Dimensions

Weight (lb)
2.7
Length (in.)
2.25
Width (in.)
5
Height (in.)
5.5

Details

UPC
697285231566
Manufacturer Part No
23156-0045
Brand Name
Cash Acme
Minimum Working Temperature
180 deg. F
Size
1 in.
Product Type
Valve
Average Lead Content
Less than 0.25 %
Connections
FIP and Sweat Copper
Thread Type
Double Union
Material
Bronze
Packaging Type
Boxed
Minimum Pressure
10 psi
Maximum Temperature
180 deg. F
Valve Type
Pressure Reducing Valve
Maximum Pressure
400 psi
End 1 Size
1 in.
Body Material
Bronze
Minimum Temperature
180 deg. F
Maximum Temperature
180 °F
Minimum Temperature
180 °F
